Rocky RK12

The new member of a familiar family!

Rocky RK12

The new generation with unique IP65 safety concept

The new generation Rocky model remains true to the roda product philosophy. A form factor that has remained constant to the previous generations, and the unique IP65 protection concept, guarantee that water and dust don't pose any hazard, even with uncovered interfaces and removed drives. Performance has been greatly enhanced, with a stronger Intel® platform and more working memory. Great importance was placed on hardware compatibility with the Microsoft Windows 10 and Windows 7 operating systems.

The Rocky RK12 is perfectly suited as a computer for installation in protected and armoured vehicles and aircrafts, with the addition of military connectors and suitable accessories – which is greatly appreciated by many users.

Technical specifications

Display

    • LCD 15.1“ XGA (1024×768)
    • LED backlight
    • sunlight readable
    • optical bonding

Chipset

    • Intel® Skylake platform
    • Mobile Intel® QM170 Express Chipset

CPU

    • Intel® Core™i7-6822EQ™,
    • 2.0 GHz (2.8 GHz max. Turbo Frequency)

Graphics

    • Intel® HD Graphics 530

Memory

    • up to 32 GB DDR4 2133 MHz (2x slots)

Storage

    • exchangeable 2,5”SATA HDD (up to 500 GB)
    • >> optional SATA SSD (up to 1000 GB)

ODD

    • exchangeable DVD±RW drive (FlexBay)

Audio

    • HD audio, stereo speaker

Touchpad

    • resistive

Power supply

    • Li-Ion battery, 10.8 V, 8700 mAh
    • AC-adapter 90 W, 19 VDC, 3.4 A, 100~240 VAC, 50/60 Hz

Interfaces (left side)

    • 3x Audio (3.5mm)
    • 1x Gigabit LAN (RJ45)
    • 2x USB 2.0 (1x fast charge)
    • 2x USB 3.0
    • 1x PS/2
    • 1x Express Card (PCIe)

Interfaces (rear side)

    • 1x DC-In
    • 2x serial (DB9)
    • 1x Displayport
    • 1x VGA (DB15)
    • 1x RD-DVI (*RD = roda Display remote)
    • 1x docking connector

Security

    • TPM2.0 module

Operating Systems

    • Windows 7
    • Windows 10

Certification

    • CE, FCC, WHQL, WEEE, REACH
    • IP65 (with opened I/O-ports)
    • MIL-STD-810G

Housing

    • rugged magnesium housing

Colour

    • military green (NATO olive / RAL6031HR)
    • black

Dimensions

    • 353 x 301 x 79.2 mm (L x D x H)

Weight

    • 5.5 kg

Options

  • SXGA+ resolution (1400x1050)
  • optional LCD brightness up to 1000 cd/m²
  • I-Temp MLC, pSLC or SLC SSD (-45°C to + 85°C)
  • heater for -30°C operating
  • touch screen resistive, sunlight readable
  • 4x RS232/422/485 external interfaces
  • 2nd LAN card 10/100/1000 MBit
  • fibre optic LC or HMC connector (100FX, 1000LX oder 1000SX)
  • WLAN card (802.11a/g/n/ac) incl. Bluetooth v2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0(BLE)
  • UMTS / HSDPA module
  • GPS module
  • integrated Chip/Smart Card Reader class 1
  • internal vehicle adapter (direct 12 VDC- 32 VDC) incl. SP200 module / surge protector
  • different keyboard versions available
  • isolated Housing for vehicle installation
  • military grade connectors for nearly all kind of interfaces on request
  • TEMPEST SDIP 27 Level B (ER)
  • MIL-STD-461G certification
    • Ground Navy (Navy fixed & Air Force)
    • Ground Army (Naviy mobile & Army)

Accessories


DC converter MIL for vehicle installation
DockUnder port replicator
Replacement AC adaptor
90 watts
External DC adaptor
Mounting plate for vehicle installation
Transport bag
