Note: This product will be end-of-life in October 2022 and with a Last Time Buy until April 2023 at the latest. The successor model Panther DH8 will be available from October 2022!

Panther DB7

Full-rugged 5" ultra-mobile PC

Small and sophisticated, but a truly rugged mobile PC. It's innovative technology makes it ideal for mobile use – when every gram counts and every centimetre forms an obstacle – while still offering proven resistance to environmental influences and great mobility (690 g). It offers the full range of functions of a normal PC and a large variety of interfaces via MIL connectors, and still only takes up minimum space with a display size of 5" (diagonal). Like all other Panther models, the Panther DB7 convinces through its IP65, MIL-STD810, and MIL-STD461 certifications.

Technical specifications

Display

  • LCD 5“ WVGA (800 x 480)
  • LED backlight
  • Sunlight readable

Touch

  • Resistive touch screen

CPU

  • Intel® Atom™ E3825 dual core processor, 1 MB cache, up to 1.33 GHz

Chipset

  • Intel® Bay Trail-I

Graphics

  • Intel® HD Graphics

Memory

  • DDR3L 1066 MHz
  • up to 8 GB (1x SO-DIMM slot)

Storage

  • mSATA SSD

Camera

  • Optional: Webcam 5MP (rear side)

Interfaces

  • 1x USB2.0
  • 1x SD card slot
  • 1x SIM card slot
  • 1x Cradle connector (POGO-pin)
  • Optional:
    • 1x Cradle docking station
    • 1x Expansion connector (bottom side)
    • up to 2x MIL Hirose connector (top side)

Connectivity [WLAN / BT / GPS]

  • Optional: Intel® Centrino® Advanced-N 6235
    • WLAN 802.11 a/b/g/n
    • Bluetooth 4.0
  • Optional: Ublox Neo-M8N GPS/GLONASS

Power supply

  • Li-Ion battery, 7.4 V, 3900 mAh
  • AC-adaptor 36 W, 100-240 V, 50-60 Hz
  • Integrated vehicle adaptor 12-32 V with surge protection

Security

  • TPM 2.0
  • fingerprint scanner

Operating System

  • Windows 10 Pro

Dimensions [W×H×D]

  • 202.2 x 97.9 x 40 mm

Weight

  • 690 g

Protection class

  • IP65

Certification

  • MIL-STD-810G
  • MIL-STD-461G Ground Navy
